Flexible Manufacturing System (Model : XPO-FMS)

This multi-technology enabled training system is designed for STEM-based education, preparing students for careers in a range of disciplines. The system encompasses electro-pneumatics, mechanical engineering, electronic controls, automation, sensor technology, electrical motors, production engineering, PLC programming, and optionally, robotics. The simulated auto component’s mass production technique is divided into four stations, each programmable and operable individually, allowing students to gain hands-on experience in various technologies. The industrial-quality equipment provides a realistic experience, immersing students in an environment that closely mirrors real industrial settings.

Category:

SALIENT FEATURES:

  • Useful for STEM based education. Will prepare students for their careers using multi technology enabled training system consisting of electro-pneumatic, mechanical, electronic controls, Automation, sensor technology, electrical motors, production engineering, PLC programming, robotics (optional) etc.
  • Mass production technique of a simulated auto component is split into 4 stations, each of which can be individually programmed/operated/trained.
  • Industrial quality equipment makes students feel like they are actually training in real industrial setting so that students are better prepared for the entire scope of the technologies they will encounter.
  • Working with various mechanisms & hardware by students using 4mm patch cords.
  • Provided curriculum helps to teach troubleshooting with organized problem-solving methods & changing PLC programs etc.
  • Optionally Industry 4.0 compatible FMS with SCADA (Wincc) for cloud based MIS & HMI for smart factory demonstration, PC (Win10 or better) not inscope of supply.

Technical Specifications

Mechanical Dimensions:

  • Individual stations Mounted on profile plates of 500×350 mm joined together lengthwise using 2 nos. of long (4 screw) T nuts, laid out on 2 meter table top,
  • Optionally 4 floor standing profile tables mounted setup may be provided.

Accessories:

  • Compressor : single phase, 6-8 bars, 3 CFM with QRC socket PU 6×4 tube.
  • 4mm Patch cords set.
  • D connector cable set – 37 pin D(1), 9 pin D (7), 15 pin D (1).
  •  SW & IG manuals – 1no for FMS & 2nos for XPO-PLC (refer XPO-PLC leaflet)

List of experiments:

  • Working with station pneumatics
  • Working with FMS.
    Optional: Working with Industry 4.0 compatible FMS with SCADA for cloud based MIS & HMI for smart factory demonstration. Order SCADA & HMI separately (PC is not in scope of supply).
